MM-5 Coffee Cup Engine Kit
( You may make submit credit card payments via our website: http://stirlingengine.com/product/25 )
Note: The coffee cup, tools, glue, and epoxy shown in the pictures are not included. The DVD has been replaced by written instructions.
This kit includes all the parts to build our original transparent MM-1 stirling engine that sells ready to run for $178.95.
Our Price: $118.95
Ready to assemble. You only need to purchase superglue and silicone sealant. You will also need a few common hand tools to assemble your engine. It's a pleasant two or three evening kit and a fun way to learn about Stirling engines. To enjoy a video clip or Flash animation of this engine go to:
http://stirlingengine.com/product/25
You may want to have a Spare Diaphragm on hand. This is the only wear part in the engine.
The United States Naval Academy has their mechanical engineering students build one of our kits.
If you want a very easy to build kit, we recommend our homopolar electric motor kit.
For video clips of the MM-5 running on a cup of hot coffee and on cold Breyers ice cream, go to:
http://stirlingengine.com/product/21
-----
